VKJ-6550 Professional X-Ray Baggage Scanner

Dual-View Imaging Configuration

The VKJ-150180D supports two dual-view configurations to suit different operational workflows:

• Top-Bottom View: One X-ray generator positioned above and one below the tunnel, capturing overhead and underside perspectives simultaneously.
• Side-Side View: Two X-ray generators mounted on opposite sides of the tunnel, delivering left and right lateral views for comprehensive inspection coverage.

This dual-angle approach eliminates blind spots and provides operators with complementary visual data, enabling faster and more accurate screening decisions.

Technical Specifications

Key Features

• Dual-View Architecture: Two independent X-ray imaging chains capture orthogonal views simultaneously, reducing inspection time and improving detection accuracy.
• Image Enhancement: Advanced algorithms for contrast adjustment, edge sharpening, and histogram equalization for optimal image clarity.
• Material Viewing: Color-coded material classification helps operators quickly distinguish between organic, inorganic, and mixed materials.
• Zoom & Playback: Real-time zoom (up to 64×) and recorded playback functionality for detailed post-scan review.
• High-Capacity Storage: Built-in storage for 100,000+ scanned images with search and retrieval capabilities.
• Ultra-Low Radiation Leakage: Leakage dose below 0.1 µGy/h, meeting international safety standards for operator and environmental protection.
• Industrial-Grade Construction: Heavy-duty steel frame and conveyor rated for continuous operation in demanding logistics environments.

Applications

The VKJ-150180D is purpose-built for high-volume commercial and industrial screening environments:

• Cargo terminals and freight inspection stations
• Logistics parks and distribution centers
• Heavy freight warehouses and cross-dock facilities
• Pallet handling and bulk cargo screening
• Industrial supply chain security checkpoints
